P 0205-CYLIN D ER 5-IN J ECTOR CIRCU IT SHORTED TO GROU N D
Wh en Mon it or ed: Wit h t h e en gin e r u nn in g.
Set Con dition : Th e E CM det ect s a sh or t t o gr ou nd on t h e Cylin der #5 In ject or cir cuit .
P 0205-CYLIN D ER 5-IN J ECTOR CIRCU IT SHORTED TO VOLTAGE
Wh en Mon it or ed: Wit h t h e en gin e r u nn in g.
Set Con dition : Th e E CM det ect s a sh or t t o volt age on t h e Cylin der #5 In ject or cir cuit .
POSSIBLE CAUSES
CH E CKING ECM POWE R AN D GROUN DS
CH E CKIN G TH E E NGIN E CONTROL RE LAY S YSTE M
ENGINE CONTROL MODULE
INTERMITTENT CONDITION
FUE L INJ E CTOR CONTROL CIRCU IT SH ORTE D TO VOLTAGE
FUEL INJECTOR CONTROL CIRCUIT SHORTED TO GROUND
FUEL INJECTOR CIRCUITS SHORTED TOGETHER
FUEL INJECTOR CONTROL CIRCUIT OPEN
FUEL INJECTOR
TE S T ACTION AP PLICAB ILITY
1 NOTE: If the ECM detects and stores a DTC, the ECM also stores the
e n gi n e /ve h ic le o p e ra ti n g c o n d i tio n s u n d e r w h ic h th e D TC w a s s e t. S o m e o f
these conditions are displayed on the DRB at the same time the DTC is
displayed.
NOTE: Before erasing stored DTCs, record these conditions. Attempting to
duplicate these conditions may assist when checking for an active DTC.
Tur n th e ign it ion on .
Wit h th e DRBIII",erasetheECMDTCs.
Att em pt to st a r t th e en gin e an d t est dr ive th e veh icle.
Wit h th e DRBIII",readtheECMDTCs.
Did t h is DTC set a ga in ?
All
Ye s → Go To 2
No → Go To 8
63
DRI V EABI LI T Y - DI ESEL
P 0201-CYLIN DER 1-IN J ECTOR CIRCU IT EXCES SIVE CU RREN T —
Co n t in ued
