TE S T ACTION AP PLICAB ILITY
3 Tur n th e ign it ion off t o t h e lock posit ion .
Discon n ect t he TCM C2 ha r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or.
NOTE: Ch e c k c o n n e c to rs - Cle an /re pa i r a s n e c e ss a ry.
Mea su r e th e r esist a n ce of bot h th e CAN C Bu s (+) cir cu it a n d th e CAN C Bu s (-)
cir cu it bet ween t he TCM C2 ha r n ess con n ect or a n d E CM h a rn ess con n ect or.
Is t h e resista n ce below 10.0 ohm s for ea ch mea su rem en t ?
All
Ye s → Repla ce th e En gin e Con t r ol Module in a ccorda n ce wit h t he
Ser vice In for m a t ion .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Repa ir t h e CAN C Bu s (+) a nd/or CAN C Bu s (-) cir cu it for an
open .
Per for m BODY VERIFICATION TE ST - VE R 1.
4 WARN IN G: WHEN THE E N GIN E IS OP ERATIN G, D O N OT STAN D IN A
DIR ECT LIN E WITH THE FAN . D O N OT P UT YOU R HAN D S NEAR THE
P ULLEYS , B ELTS OR FAN . D O NOT WEAR LOOS E CLOTHIN G.
NOTE: The conditions that set the DTC are not present at this time. The
fo ll o wi n g l is t ma y h e l p i n id en t i fy ing the i n t e rmi tt e nt c o nd i ti o n .
Wit h t h e en gin e r u n n in g a t n or m a l oper a t in g t em per a t u r e, m onit or t h e DRB
pa r a m et er s rela ted t o t h e DTC while wiggling th e wir ing ha r n ess. Look for pa r a m -
et er va lu es t o ch a n ge a n d/or a DTC to set .
Review t h e DTC Wh en Monit or ed a n d Set Con dit ion s. If possible, t r y to du plica t e t h e
condit ion s u n der wh ich t h e DTC wa s set .
Refer t o a n y Tech n ica l Service Bu llet in s (TSB) t h a t m a y a pply.
Visu a lly in spect t h e rela t ed wirin g h a r n ess. Look for a n y ch a fed, pier ced, pin ched, or
pa r t ia lly br oken wir es.
Visu a lly in spect t h e r ela t ed wir ing h a r n ess conn ect or s. Look for br oken , ben t , pu sh ed
out , or cor r oded t er m in a ls.
Wer e an y of t h e above condit ion s pr esen t ?
All
Ye s → Repa ir a s n ecessa ry.
Per for m BODY VERIFICATION TE ST - VE R 1.
No → Test Com plet e.
72
DRI V EABI LI T Y - DI ESEL
P 0600-CAN D ATA BU S - BU S CIRCUIT FAU LT — Co nt in ued
To Next Page
