TE S T ACTION AP PLICAB ILITY
1 NOTE: If DTC P1611, P2306 or P2332 is present with this DTC, diagnose
DTCs P1611, P2306 or P2332 before diagnosing this DTC.
NOTE: If the ECM detects and stores a DTC, the ECM also stores the
e n gi n e /ve h ic le o p e ra ti n g c o n d i tio n s u n d e r w h ic h th e D TC w a s s e t. S o m e o f
these conditions are displayed on the DRB at the same time the DTC is
displayed.
NOTE: Before erasing stored DTCs, record these conditions. Attempting to
duplicate these conditions may assist when checking for an active DTC.
NOTE: The engine oil must be at the proper level for this test to be valid.
Refer to the Service Information and ensure the engine oil level is at the
specified level.
Tur n th e ign it ion on .
Wit h th e DRB, er a se E CM DTCs.
St a r t t h e en gin e sever a l tim es, let t ing th e en gin e r u n for at lea st 30 secon ds a t a
time.
Wit h th e DRB, r ea d E CM DTCs.
Did t h is DTC set a ga in ?
All
Ye s → Go To 2
No → Go To 10
2 WARN IN G: WHEN THE E N GIN E IS OP ERATIN G, D O N OT STAN D IN A
DIR ECT LIN E WITH THE FAN . D O N OT P UT YOU R HAN D S NEAR THE
P ULLEYS , B ELTS OR FAN . D O NOT WEAR LOOS E CLOTHIN G.
Refer t o a n y Tech n ica l Service Bu llet in s (TSB) t h a t m a y a pply.
Tur n th e ign it ion off.
NOTE: This DTC implies that the engine may be contaminated by water,
engine coolant or other material due to a mechanical or service failures
such as failed gaskets, seals, cracks or incorrectly installed components.
In spect t h e en gin e for con dit ion s r efer r ed t o in t h e above not e.
Wer e an y of t h e above condit ion s pr esen t ?
All
Ye s → Repa ir a s n ecessa ry.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Go To 3
3 Tur n th e ign it ion off.
Discon n ect t he E n gin e Oil Sen sor ha r n ess con n ect or.
Tur n th e ign it ion on .
Mea su r e th e volt a ge of th e E ngin e Oil Sen sor Sign a l cir cu it .
Select t h e appr opr ia t e volt age rea din g.
All
Volt a ge i s a bove 5.4 volt s.
Go To 4
Volt a ge i s bet ween 4.7 an d 5.4 volt s.
Go To 5
Volt a ge i s below 4.7 volt s.
Go To 7
114
DRI V EABI LI T Y - DI ESEL
P 2014-ENGIN E OIL S EN S OR OIL TEMP ERATU RE P LAU S IB ILITY —
Co n t in ued
