TE S T ACTION AP PLICAB ILITY
16 WAR N IN G: WHEN TH E EN GIN E IS OP ERATIN G, D O N OT STAN D IN A
DIR ECT LIN E WITH THE FAN . D O N OT P UT YOU R HAN D S NEAR THE
P ULLEYS , B ELTS OR FAN . D O NOT WEAR LOOS E CLOTHIN G.
NOTE: The conditions that set the DTC are not present at this time. The
fo ll o wi n g l is t ma y h e l p i n id en t i fy ing the i n t e rmi tt e nt c o nd i ti o n .
Wit h t he en gin e r u n n in g an d a t n orm a l oper a t in g t em per a t u r e, mon it or t h e DRB
pa r a m et er s rela ted t o t h e DTC while wiggling th e wir ing ha r n ess. Look for pa r a m -
et er va lu es t o ch a n ge a n d/or a DTC to set .
Rem ove t h e CMP Sen sor a n d th e CKP Sen sor, checking for loose m ou n t in g scr ews
an d debr is on t he sen sor ma gn et s t h a t ca n corr u pt t h e sen sor sign a l.
Refer t o a n y Tech n ica l Service Bu llet in s (TSB) t h a t m a y a pply.
Visu a lly in spect t h e rela t ed wirin g h a r n ess. Look for a n y ch a fed, pier ced, pin ched, or
pa r t ia lly br oken wir es.
Visu a lly in spect t h e r ela t ed wir ing h a r n ess conn ect or s. Look for br oken , ben t , pu sh ed
out , or cor r oded t er m in a ls.
Wer e an y of t h e above condit ion s pr esen t ?
All
Ye s → Repa ir a s n ecessa ry.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Test Com plet e.
145
DRI V EABI LI T Y - DI ESEL
P 2043-CAMS HAF T P OS ITION S EN SOR CIRCU IT OP EN CIRCUIT —
Co n t in ued
