Symptom List:
P 2100-F U EL P U MP RELAY CIRCU IT SHORTED TO VOLTAGE
P 2100-F U EL P U MP RELAY EXCES S IVE CU RREN T
Te s t N o t e : Al l s y m p t o m s l i s t e d a b o v e a r e d i a g n o s e d u s i n g t h e s a m e t e s t s .
Th e title fo r th e te sts w ill be P 2100-F U EL P UMP RELAY
CIRCU IT S HORTED TO VOLTAGE.
POSSIBLE CAUSES
INTERMITTENT CONDITION
FUEL LIFT PUMP RELAY
FUE L LIF T PUMP RE LAY CONTROL CIRCUIT SH ORTE D TO VOLTAGE
ENGINE CONTROL MODULE
TE S T ACTION AP PLICAB ILITY
1 NOTE: If the ECM detects and stores a DTC, the ECM also stores the
e n gi n e /ve h ic le o p e ra ti n g c o n d i tio n s u n d e r w h ic h th e D TC w a s s e t. S o m e o f
these conditions are displayed on the DRB at the same time the DTC is
displayed.
NOTE: Before erasing stored DTCs, record these conditions. Attempting to
duplicate these conditions may assist when checking for an active DTC.
Tur n th e ign it ion on .
Wit h th e DRB, a ct u a t e th e Fu el Lift Pu m p Rela y.
Does t h e Fu el Lift P u m p Rela y cycle on an d off?
All
Ye s → Go To 2
No → Go To 3
2 WARN IN G: WHEN THE E N GIN E IS OP ERATIN G, D O N OT STAN D IN A
DIR ECT LIN E WITH THE FAN . D O N OT P UT YOU R HAN D S NEAR THE
P ULLEYS , B ELTS OR FAN . D O NOT WEAR LOOS E CLOTHIN G.
NOTE: The conditions that set the DTC are not present at this time. The
fo ll o wi n g l is t ma y h e l p i n id en t i fy ing the i n t e rmi tt e nt c o nd i ti o n .
Wit h t h e en gin e r u n n in g a t n or m a l oper a t in g t em per a t u r e, m onit or t h e DRB
pa r a m et er s rela ted t o t h e DTC while wiggling th e wir ing ha r n ess. Look for pa r a m -
et er va lu es t o ch a n ge a n d/or a DTC to set .
Review t h e DTC Wh en Monit or ed a n d Set Con dit ion s. If possible, t r y to du plica t e t h e
condit ion s u n der wh ich t h e DTC wa s set .
Refer t o a n y Tech n ica l Service Bu llet in s (TSB) t h a t m a y a pply.
Visu a lly in spect t h e rela t ed wirin g h a r n ess. Look for a n y ch a fed, pier ced, pin ched, or
pa r t ia lly br oken wir es.
Visu a lly in spect t h e r ela t ed wir ing h a r n ess conn ect or s. Look for br oken , ben t , pu sh ed
out , or cor r oded t er m in a ls.
Wer e an y of t h e above condit ion s pr esen t ?
All
Ye s → Repa ir a s n ecessa ry.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Test Com plet e.
159
DRI V EABI LI T Y - DI ESEL
