TE S T ACTION AP PLICAB ILITY
3 Tur n th e ign it ion off.
Discon n ect t he ABS Modu le ha r n ess conn ect or s.
NOTE: This code can be caused by an intermittent problem in the wiring
and connectors to the ABS Module. Inspect the ABS harness connector and
associated wiring for signs of poor terminal contact.
Tur n th e ign it ion on .
Mea su r e an d not e t h e volt a ge of bot h CAN Bu s cir cu it a t t h e ABS Module ha r n ess
conn ect or.
Is t h e volt a ge bet ween 2.2 volt s a n d 2.8 volt s for ea ch m ea su r em en t ?
All
Ye s → Test Com plete.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Repa ir th e CAN Bu s cir cu it (s) for a n open .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
4 WARN IN G: WHEN THE E N GIN E IS OP ERATIN G, D O N OT STAN D IN A
DIR ECT LIN E WITH THE FAN . D O N OT P UT YOU R HAN D S NEAR THE
P ULLEYS , B ELTS OR FAN . D O NOT WEAR LOOS E CLOTHIN G.
NOTE: The conditions that set the DTC are not present at this time. The
fo ll o wi n g l is t ma y h e l p i n id en t i fy ing the i n t e rmi tt e nt c o nd i ti o n .
Wit h t h e en gin e r u n n in g a t n or m a l oper a t in g t em per a t u r e, m onit or t h e DRB
pa r a m et er s rela ted t o t h e DTC while wiggling th e wir ing ha r n ess. Look for pa r a m -
et er va lu es t o ch a n ge a n d/or a DTC to set .
Review t h e DTC Wh en Monit or ed a n d Set Con dit ion s. If possible, t r y to du plica t e t h e
condit ion s u n der wh ich t h e DTC wa s set .
Refer t o a n y Tech n ica l Service Bu llet in s (TSB) t h a t m a y a pply.
Visu a lly in spect t h e rela t ed wirin g h a r n ess. Look for a n y ch a fed, pier ced, pin ched, or
pa r t ia lly br oken wir es.
Visu a lly in spect t h e r ela t ed wir ing h a r n ess conn ect or s. Look for br oken , ben t , pu sh ed
out , or cor r oded t er m in a ls.
Wer e an y of t h e above condit ion s pr esen t ?
All
Ye s → Repa ir a s n ecessa ry.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Test Com plet e.
185
DRI V EABI LI T Y - DI ESEL
P 2210-ESM CAN MES S A GE MISS IN G OR IN CORRECT — Co nt in ued
To Next Page
