TE S T ACTION AP PLICAB ILITY
4 Tur n th e ign it ion off.
Discon n ect t he F u el P r essu r e Sen sor ha r n ess con n ector.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e th e r esist a n ce between t h e Sen sor Gr ou nd cir cu it a n d th e F u el P r essu r e
Sen sor Sign a l cir cuit at t h e Fu el P r essu r e Sen sor h a rn ess con n ect or.
Is t h e resista n ce a bove 1000 ohm s?
All
Ye s → Go To 5
No → Repa ir th e Fu el P r essu r e Sen sor Sign a l cir cu it for a shor t t o t he
Sen sor Gr ou n d cir cu it .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
5 Tur n th e ign it ion off.
Discon n ect t he Boost P r essu r e Sensor h ar n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e t he r esist an ce bet ween t h e Sen sor Gr ou n d cir cu it an d th e Boost P r essu r e
Sen sor Sign a l cir cuit at t h e Boost P r essu r e Sen sor h a r ness con n ect or.
Is t h e resista n ce a bove 1000 ohm s?
All
Ye s → Go To 6
No → Repa ir th e Boost P r essu re Sen sor Sign a l cir cu it for a sh or t to t h e
Sen sor Gr ou n d cir cu it .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
6 Tur n th e ign it ion off.
Discon n ect t he Boost P r essu r e Sensor h ar n ess con n ect or.
Tur n th e ign it ion on .
Wit h th e DRBIII",eraseECMDTCs.
Tur n th e ign it ion off for 10 secon ds. Tur n th e ign it ion on.
Wit h th e DRBIII",readECMDTCs.
Does t h e DRB displa y t h is DTC?
All
Ye s → Go To 7
No → Repla ce th e Boost Pr essur e Sen sor.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
7 Tur n th e ign it ion off.
Discon n ect t he F u el P r essu r e Sen sor ha r n ess con n ector.
Tur n th e ign it ion on .
Wit h th e DRBIII",eraseECMDTCs.
Tur n th e ign it ion off for 10 secon ds. Tur n th e ign it ion on.
Wit h th e DRBIII",readECMDTCs.
Does t h e DRB displa y t h is DTC?
All
Ye s → Repla ce a nd pr ogr a m t h e En gin e Con t r ol Modu le in a ccor da n ce
wit h th e Ser vice In for m a t ion .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Repla ce th e Fu el Pr essu r e Sen sor.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
201
DRI V EABI LI T Y - DI ESEL
P 2306-S EN S OR S UP P LY 2 VOLTAGE IS TOO LOW — Co n t i n u e d
