TE S T ACTION AP PLICAB ILITY
4 Tur n th e ign it ion off.
Discon n ect t he E n gin e Oil Sen sor ha r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e t he r esist an ce bet ween t h e Sen sor Gr ou n d cir cu it an d th e E n gin e Oil Sen sor
Sign al cir cu it at t he E n gin e Oil Sen sor ha r n ess con n ect or.
Is t h e resista n ce a bove 1000 ohm s?
All
Ye s → Go To 5
No → Repa ir th e E n gin e Oil Sen sor Sign a l cir cu it for a sh or t to th e
Sen sor Gr ou n d cir cu it .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
5 Tur n th e ign it ion off.
Discon n ect t he In t a ke Air Pr essu r e Sen sor h a r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e t h e resist an ce between t h e Sen sor Gr ou n d cir cu it a n d t h e In t a ke Air
Pr essu r e Sen sor Sign a l cir cu it a t th e In t a k e Air P ressur e Sensor h a r n ess conn ect or.
Is t h e resista n ce a bove 1000 ohm s?
All
Ye s → Go To 6
No → Repa ir t h e In t a ke Air Pr essu r e Sen sor Sign a l circu it for a sh or t t o
th e Sen sor Gr ou n d cir cu it .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
6 Tur n th e ign it ion off.
Discon n ect t he In t a ke Air Pr essu r e Sen sor h a r n ess con n ect or.
Tur n th e ign it ion on .
Wit h th e DRBIII",eraseECMDTCs.
Tur n th e ign it ion off for 10 secon ds. Tur n th e ign it ion on.
Wit h th e DRBIII",readECMDTCs.
Does t h e DRB displa y t h is DTC?
All
Ye s → Go To 7
No → Repla ce th e In t a ke Air Pr essu r e Sen sor.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
7 Tur n th e ign it ion off.
Discon n ect t he E n gin e Oil Sen sor ha r n ess con n ect or.
Tur n th e ign it ion on .
Wit h th e DRBIII",eraseECMDTCs.
Tur n th e ign it ion off for 10 secon ds. Tur n th e ign it ion on.
Wit h th e DRBIII",readECMDTCs.
Does t h e DRB displa y t h is DTC?
All
Ye s → Repla ce a nd pr ogr a m t h e En gin e Con t r ol Modu le in a ccor da n ce
wit h th e Ser vice In for m a t ion .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Repla ce th e En gin e Oil Sensor.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
204
DRI V EABI LI T Y - DI ESEL
P 2332-S EN S OR S UP P LY 3 VOLTAGE IS TOO LOW — Co n t i n u e d
