TE S T ACTION AP PLICAB ILITY
3 Tur n th e ign it ion off.
Discon n ect th e In t a ke Air Pr essu r e Sen sor a n d En gin e Oil Sen sor ha r n ess con n ec-
tor s.
Discon n ect t he E CM ha r n ess con n ect or s.
Rem ove t h e E ngin e Con t r ol Rela y.
Con n ect a ju mper wir e bet ween ca vit y 30 a n d ca vit y 87 of t h e En gin e Con t r ol Rela y
conn ect or in F use Block No.1.
Tur n th e ign it ion on .
Mea su r e t h e volta ge a t all cir cu it s in th e E n gin e Oil Sen sor an d In t a ke Air P r essu r e
Sen sor ha r n ess con n ect or ca vit ies.
Is t h e volt a ge above 1.0 volt for an y of t h e mea su rem en t s?
All
Ye s → Repa ir t h e cir cu it (s) t h a t m ea su r ed above 1.0 volt for a sh or t t o
volt a ge.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Go To 4
4 Tur n th e ign it ion off.
Discon n ect t he E n gin e Oil Sen sor ha r n ess con n ect or.
Tur n th e ign it ion on .
Wit h th e DRBIII",eraseECMDTCs.
Tur n th e ign it ion off for 10 secon ds. Tur n th e ign it ion on.
Wit h th e DRBIII",readECMDTCs.
Does t h e DRB displa y t h is DTC?
All
Ye s → Go To 5
No → Repla ce th e En gin e Oil Sensor.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
5 Tur n th e ign it ion off.
Discon n ect t he In t a ke Air Pr essu r e Sen sor h a r n ess con n ect or.
Tur n th e ign it ion on .
Wit h th e DRBIII",eraseECMDTCs.
Tur n th e ign it ion off for 10 secon ds. Tur n th e ign it ion on.
Wit h th e DRBIII",readECMDTCs.
Does t h e DRB displa y t h is DTC?
All
Ye s → Repla ce a nd pr ogr a m t h e En gin e Con t r ol Modu le in a ccor da n ce
wit h th e Ser vice In for m a t ion .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Repla ce th e In t a ke Air Pr essu r e Sen sor.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
207
DRI V EABI LI T Y - DI ESEL
P 2332-S EN S OR S UP P LY 3 VOLTAGE IS TOO HIGH — Co n t i n u ed
