TE S T ACTION AP PLICAB ILITY
4 Tur n th e ign it ion off.
Rem ove t h e CKP Sen sor.
In spect t h e CKP Sen sor for con dition s su ch a s loose mou n t in g screws, da m a ge or
debris.
Is t h er e an y eviden ce of t h ese condit ion s?
All
Ye s → Repa ir a s n ecessa ry.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Go To 5
5 Tur n th e ign it ion off.
Usin g th e DRB la b scope, ba ckpr obe t h e CMP Sen sor Sign a l cir cu it a t th e CMP
Sen sor ha r n ess con n ect or.
St a r t t h e en gin e, if th e en gin e will n ot st a r t , cr a n k t h e en gin e for sever a l secon ds
wh ile mon it or in g th e DRB.
NOTE: Refer to Charts and Graphs to view a correct CMP Sensor signal.
Does t h e DRB displa y a st ea dy clea n CMP Sign a l pa tt er n ?
All
Ye s → Go To 6
No → P er for m Test for DTC P 2043-Ca m sh a ft P osit ion Sen sor Cir cu it
Stat ic Plau sibility.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
6 Tur n th e ign it ion off.
Usin g th e DRB lab scope, ba ck pr obe bot h of t h e CKP Sen sor Sign al cir cu it s at t h e
CKP Sen sor h a r n ess con n ect or.
NOTE: Refer to Charts and Graphs to view a correct CKP Sensor signal.
St a r t t h e en gin e, if th e en gin e will n ot st a r t , cr a n k t h e en gin e for sever a l secon ds
wh ile mon it or in g th e DRB.
Does t h e DRB displa y a st ea dy clea n CKP Sign a l pa tt er n for ea ch cir cu it ?
All
Ye s → Go To 7
No → P er for m Test for DTC P2045-Cr a n ksha ft P osit ion Sen sor Cir cu it
Dyn a m ic P la u sibilit y.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
7 Refer t o t h e Ser vice Infor m a t ion a n d check align m en t of th e ca m sh a ft sprock et ,
cra n k sh a ft spr ocket an d inject ion pu m p spr ock et .
Are a ll of t h e spr ocket s a ligned cor r ect ly?
All
Ye s → Repla ce a nd pr ogr a m t h e En gin e Con t r ol Modu le in a ccor da n ce
wit h th e Ser vice In for m a t ion .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Repa ir or adju st as n ecessa r y.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
230
DRI V EABI LI T Y - DI ESEL
P 2606-CMP /CKP S YN CHRON IZATION ERROR — Co n t i n u ed
