TE S T ACTION AP PLICAB ILITY
9 Tur n th e ign it ion off.
Using the DRBIII" la b scope, ba ck pr obe bot h of t h e CKP Sen sor Signa l cir cu it s at t h e
ECM h a rn ess con n ect or.
NOTE: Refer to Charts and Graphs to view a correct CKP Sensor signal.
St a r t t h e en gin e, if th e en gin e will n ot st a r t , cr a n k t h e en gin e for sever a l secon ds
wh ile mon it or in g th e DRBIII".
Does t h e DRBIII" displa y a st ea dy clea n CKP Sign a l pat t er n for ea ch cir cu it ?
All
Ye s → Go To 10
No → P er for m Test for DTC P2045-Cr a n ksha ft P osit ion Sen sor Cir cu it
Dyn a m ic P la u sibilit y.
Per for m NO START VERIF ICATION - VER-1.
10 Refer t o t h e Service In form a t ion t o en su re th e E n gin e Dr ive Gea r s/Spr ocket ar e
in st a lled cor rect ly a n d t he ca m sh a ft a n d cra n k sh a ft gea r s a r e t im ed cor r ect ly.
Wer e an y pr oblem s fou n d?
All
Ye s → Repa ir a s n ecessa ry.
Per for m NO START VERIF ICATION - VER-1.
No → Repla ce an d pr ogr a m t h e E ngin e Con t r ol Modu le in a ccor da n ce
wit h th e Ser vice In for m a t ion .
Per for m NO START VERIF ICATION - VER-1.
241
DRI V EABI LI T Y - DI ESEL
*EN GIN E CRAN KS BU T WILL N OT START — Co nt in ued
To Next Page
