NO S TART VERIF ICATION - VER -1 AP P LICAB ILITY
1. N OTE: IMP ORTAN T! If th e En g in e Co n tro l Mo d u le o r S e n try Ke y Im m o bilize r
Modul e has b een r epl ace d, en sur e t he pr ogr amming pr ocedur e f or t h e modul e has
been performed in accordance w ith the Service Information.
2. In spect th e veh icle to en su r e t ha t a ll en gin e compon en t s a r e pr oper ly inst a lled a n d
conn ect ed. Reassemble an d r econ n ect compon en t s a s n ecessa r y.
3. In spect th e en gin e oil for cont a m in a t ion . If it is con t a m in a t ed, ch a n ge t h e oil a n d filt er.
4. Wit h th e DRB, er a se a ll dia gn ost ic t r ou ble codes (DTCs).
5. Tu r n th e ign it ion off for a t lea st 10 secon ds.
6. At t em pt to st a r t th e en gin e.
7. If t he en gin e is u n a ble to st a r t , look for a n y Tech nica l Ser vice Bu llet in s (TSBs) th a t m a y
rela te t o t h is con dit ion . Ret ur n t o t h e Sym pt om List if n ecessa r y.
8. If t h e en gin e sta r t s a n d con t in u es t o r u n , t h e r epa ir is n ow complet e.
Are a n y DTCs or sym pt oms r em a in ing?
All
Ye s → Repa ir is n ot complet e, r efer to a ppropr ia t e sym pt om .
No → Repa ir is com plete.
ROAD TE S T VERIF ICATION - VER -2 AP P LICAB ILITY
1. In spect th e veh icle to en su r e t ha t a ll en gin e compon en t s a r e pr oper ly inst a lled a n d
conn ect ed. Reassemble an d r econ n ect compon en t s a s n ecessa r y.
2. If t h is ver ifica t ion pr ocedu r e is bein g per for m ed a ft er a n on -DTC test , per form st eps 3 a n d
4. If n ot , pr oceed t o st ep 5.
3. Ch eck to see if t h e in it ia l sym pt om st ill exist s. If t h er e ar e no t r ou ble codes a n d th e sym pt om
no lon ger exist s, t h e repa ir wa s su ccessfu l a n d t est in g is n ow complet e.
4. If th e in it ia l or a n ot h er sym pt om exist s, t h e r epa ir is n ot com plet e. Ch eck a ll per t in en t
Tech n ica l Ser vice Bu llet in s (TSBs) a n d r et u rn t o t h e Sym pt om List if n ecessa r y.
5. F or pr eviou sly rea d DTCs th a t ha ve not been dea lt wit h , r et u r n t o t h e Sym ptom List a n d
follow th e dia gn ost ic pa t h for th a t DTC; ot h er wise, cont in ue.
6. If th e En gin e Con t r ol Modu le (ECM) h a s not been ch a n ged, per for m st eps 7 a n d 8, oth er wise,
cont in ue wit h st ep 9.
7. Wit h th e DRB III", er a se a ll dia gn ost ic t r ou ble codes (DTCs), th en discon n ect th e DRB III".
8. Tu r n th e ign it ion off for a t lea st 10 secon ds.
9. If equ ipped wit h a Tr a n sfer Ca se P osit ion Swit ch , per for m st ep 10, oth er wise, cont in u e wit h
step 11.
10. Wit h t h e ign it ion swit ch on , pla ce th e Tr a n sfer Ca se Sh ift Lever in ea ch gea r posit ion ,
st oppin g for 15 secon ds in ea ch posit ion .
11. E n su r e no DTCs r em a in by per form in g st eps 12 th r ou gh 15.
12. Roa d t est th e veh icle. F or som e of t he roa d test, go at lea st 64 km /h (40 MP H ). If th is test
is for an A/C Rela y Con t r ol Cir cu it , dr ive t he veh icle for at lea st 5 m in u t es wit h t h e A/C on.
13. At som e poin t , st op t h e veh icle a nd tu r n th e en gin e off for at lea st 10 secon ds, t h en r est a rt
th e en gin e an d con t in u e.
14. Upon complet ion of t he roa d t est , tu r n t h e en gine off an d check for DTCs with t h e DRB III".
15. If th e repa ir ed DTC h a s set a ga in , t h e repa ir is not com plet e. Ch eck for a n y per t in en t
Tech n ica l Ser vice Bu llet in s (TSBs) a nd ret u r n t o th e Sym pt om List . If t her e a r e n o DTCs, t h e
repa ir wa s su ccessfu l a n d is now com plete.
Are a n y DTCs or sym pt oms r em a in ing?
All
Ye s → Repa ir is n ot complet e, r efer to a ppropr ia t e sym pt om .
No → Repa ir is com plete.
247
VERIFICAT ION TEST S
Ve r i f i c a t i o n Te s t s — Co nt i n u e d
To Next Page
