TE S T ACTION AP PLICAB ILITY
2 WA R N I N G : T O AV O I D P E R S O N A L I N J U R Y O R D E AT H , T U R N T H E I G N I -
TION OFF, D IS CON N ECT THE B ATTE RY AN D WAIT TWO MIN U TE S B E-
FORE PROCEEDING.
Discon n ect t he P a ssen ger Airba g conn ect or (s).
NOTE: Ch e c k c o n n e c to rs - Cle an an d re p a ir a s n e c e s s a ry.
WA R N I N G : T O AV O I D P E R S O N A L I N J U R Y O R D E AT H , D O N O T P L A C E A N
IN TACT U N D EP LOYED AIR B AG FACE D OWN ON A HARD S UR FACE, THE
AIRB AG WILL P ROP EL IN TO TH E AIR IF ACCID EN TALLY D EP LOYED .
Con n ect t h e appr opria t e Loa d Tool t o t h e Pa ssen ger Air ba g con n ect or (s).
WA R N I N G : T O AV O I D P E R S O N A L I N J U R Y O R D E AT H , T U R N T H E I G N I -
TION ON , TH EN R ECON N E CT TH E B ATTE RY.
Wit h th e DRBIII", r ea d t he a ct ive Air ba g Con t r ol Module DTC’s.
Does t h e DRBIII" sh ow PASSE NGE R SQU IB 1 CIRCU IT SH ORT?
All
Ye s → Go To 3
No → Repla ce t h e Pa ssen ger Air bag in a ccor da n ce wit h t h e Ser vice
In for m a t ion .
Per for m AIRBAG VERIF ICATION TE ST - VER 1.
3 WA R N I N G : T O AV O I D P E R S O N A L I N J U R Y O R D E AT H , T U R N T H E I G N I -
TION OFF, D IS CON N ECT THE B ATTE RY AN D WAIT TWO MIN U TE S B E-
FORE PROCEEDING.
Discon n ect t he Loa d Tool fr om t h e Pa ssen ger Air bag conn ect or (s).
Discon n ect t he Air ba g Con tr ol Module conn ect or (s).
NOTE: Ch e c k c o n n e c to rs - Cle an an d re p a ir a s n e c e s s a ry.
Con n ect t h e a ppr opr ia t e Loa d Tool Ada pt er t o t h e Air ba g Con t r ol Modu le conn ec-
tor (s).
Mea su r e t h e r esist a n ce bet ween Pa ssen ger Squib 1 Lin e 1 a n d Lin e 2 cir cu it s a t t h e
Pa ssen ger Air ba g con n ect or.
Is t h e resista n ce below 10K ohm s?
All
Ye s → Repa ir Pa ssen ger Squ ib 1 Lin e 1 cir cu it sh or t t o P a ssen ger Squ ib
1 Lin e 2 cir cu it .
Per for m AIRBAG VERIF ICATION TE ST - VER 1.
No → Go To 4
4 WA R N I N G : I F T H E A I R B A G C O N T R O L M O D U L E I S D R O P P E D AT A N Y
TIME, IT MU S T B E R EP LACED . FAILU RE TO TAKE THE P R OP ER P RE -
CAU TION S COU LD RES U LT IN ACCID EN TAL AIRB AG DE P LOYMEN T
AND P ERSO NAL INJ UR Y O R DE AT H .
If t h er e ar e no possible cau ses r em a in ing, view repa ir.
All
Repa ir :
Repla ce t h e Air ba g Cont r ol Modu le in a ccor da n ce wit h Ser vice
In for m a t ion .
Per for m AIRBAG VERIF ICATION TE ST - VER 1.
60
AI RBAG
PASSENGER SQUIB 1 CIRCUIT SHORT — Co n t i n u ed
