SUSPENSION
TAB LE O F CO NTE NTS
page page
FRONT .................................1
REAR ..................................11
WHEEL ALIGNMENT . . . . . . . . . . . . . . . . . . . . . . 17
FRON T
TABLE OF CONTENTS
page page
FRONT
SPECIFICATIONS - TORQUE CHART .........1
SPECIAL TOOLS
FRONT SUSPENSION ...................2
BUSHINGS
REMOVAL .............................3
INSTALLATION ..........................3
HUB / BEARING
DIAGNOSIS AND TESTING - ...............4
REMOVAL .............................4
INSTALLATION ..........................5
KNUCKLE
REMOVAL .............................5
INSTALLATION ..........................6
LOWER BALL JOINT
REMOVAL .............................6
INSTALLATION ..........................6
LOWER CONTROL ARM
REMOVAL .............................6
INSTALLATION ..........................7
SPRING
REMOVAL .............................7
INSTALLATION ..........................8
SPRING CLAMP PLATES
REMOVAL .............................8
INSTALLATION ..........................9
SPRING STOP PLATES
REMOVAL .............................9
INSTALLATION ..........................9
STABILIZER BAR
DESCRIPTION ..........................9
OPERATION ............................9
REMOVAL .............................9
INSTALLATION ..........................9
STABILIZER LINK
REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . 10
STRUT
REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . 10
FRON T
SPECIFICATIONS - TORQUE CHART
TORQUE SPECIFICATIONS
DESCRIPTION N·m Ft. Lbs. In. Lbs.
Lower Ball Joint To Steer-
ing Knuckle
280 206 —
Strut To Steering Knuckle 185 136 —
Strut To Body 100 74 —
Bottom Spring Clamp
Plate To Front Axle
M12 X 1.5 Bolt
130 96 —
VA SUSPENSION 2 - 1
