TE S T ACTION AP PLICAB ILITY
2 WA R N I N G : N E V E R O P E R AT E T H E H E AT E R I N A N E N C L O S E D A R E A
TH AT D OES N OT HAVE EXH AU S T VEN TILATION FACILITIES . A LWAYS
VEN T THE EXHAU S T WHE N OP ERATIN G THE HE ATER. F AILU R E TO
FOLLOW TH ES E IN S TRU CTIONS CAN RES U LT IN P E RS ON AL IN J U RY
OR D E ATH .
WA R N I N G : A L L O W T H E H E AT E R A S S E M B LY T O C O O L B E F O R E P E R -
FOR MIN G A COMP ON EN T INS P E CTION /RE PAIR /REP LACE MEN T. FAIL-
UR E TO F OLLOW THES E IN STR U CTION S CAN RE SU LT IN P E RS ON AL
IN JU RY OR D E ATH .
Tur n th e ign it ion off.
Discon n ect t he ba t t er y in a ccor da n ce wit h th e Ser vice in for m a t ion .
NOTE: Ch e c k c o n n e c to rs - Cle an /re pa i r a s n e c e ss a ry.
Discon n ect t he Ca bin Hea t er or Hea t er Boost er ha r n ess con nect or.
NOTE: Ch e c k c o n n e c to rs - Cle an /re pa i r a s n e c e ss a ry.
Discon n ect t he Dosin g P u m p ha r n ess con n ect or.
Mea su r e th e resist an ce bet ween t he Dosin g P u m p Con tr ol cir cu it a n d t h e Gr ou nd
cir cu it in th e Dosin g P u m p h a r n ess con n ect or.
Is t h e resista n ce below 10K ohm s?
All
Ye s → Repa ir th e Dosin g P u m p Con t r ol circu it for a sh or t to t h e Gr ou n d
cir cu it .
Per for m H E ATE R VERIF ICATION TE ST - VER 1.
No → Go To 3
3 WA R N I N G : N E V E R O P E R AT E T H E H E AT E R I N A N E N C L O S E D A R E A
TH AT D OES N OT HAVE EXH AU S T VEN TILATION FACILITIES . A LWAYS
VEN T THE EXHAU S T WHE N OP ERATIN G THE HE ATER. F AILU R E TO
FOLLOW TH ES E IN S TRU CTIONS CAN RES U LT IN P E RS ON AL IN J U RY
OR D E ATH .
WA R N I N G : A L L O W T H E H E AT E R A S S E M B LY T O C O O L B E F O R E P E R -
FOR MIN G A COMP ON EN T INS P E CTION /RE PAIR /REP LACE MEN T. FAIL-
UR E TO F OLLOW THES E IN STR U CTION S CAN RE SU LT IN P E RS ON AL
IN JU RY OR D E ATH .
Tur n th e ign it ion off.
Discon n ect t he ba t t er y in a ccor da n ce wit h th e Ser vice in for m a t ion .
NOTE: Ch e c k c o n n e c to rs - Cle an /re pa i r a s n e c e ss a ry.
Discon n ect t he Ca bin Hea t er or Hea t er Boost er ha r n ess con nect or.
NOTE: Ch e c k c o n n e c to rs - Cle an /re pa i r a s n e c e ss a ry.
Discon n ect t he Dosin g P u m p ha r n ess con n ect or.
Mea su r e th e resista n ce between gr ou n d a n d t h e Dosin g P u m p Con t r ol cir cu it .
Is t h e resista n ce below 10K ohm s?
All
Ye s → Repa ir t h e Dosin g P u m p Con t r ol cir cu it for a sh or t to gr ou n d.
Per for m H E ATE R VERIF ICATION TE ST - VER 1.
No → Repla ce t h e Ca bin Hea t er Assem bly or H ea t er Boost er Assem bly
in accor da n ce wit h t h e Ser vice In for m a t ion .
Per for m H E ATE R VERIF ICATION TE ST - VER 1.
82
CABI N H EAT ER
DOSING PUMP SHORTED — Co n t i n u ed
To Next Page
