The X Axis Drive Assembly
7-52 DSX™ System Service Manual
To Remove the X-Transition Printed Circuit Board (Part No. 582050902):
1 Remove the two M3X6 Cap Screws and washers that secure the heat sink on the
underside of the X-Transition PCB to the right frame panel.
2 Disconnect the solenoid cable from J9 on the X-Transition PCB.
3 Remove the four M3 Nylock nuts that secure the X transition PCB to the
standoffs.
Note: The side panel must be removed to access the X-Transition PCB.
To Install a New X-Transition Printed Circuit Board:
1 Fit the X-Transition PCB to the ribbon cable tray standoffs using four M3 Nylock
nuts and four M3 Nylon washers. Do not tighten the nuts at this time.
2 Connect the solenoid cable to J9 on the X-Transition PCB.
3 Secure the heat sink on the underside of the X-Transition PCB to the right frame
panel using two M3X6 Cap Screws and washers.
4 Tighten the four M3 Nylock nuts and four M3 Nylon washers that secure the
X-Transition PCB to the tray.
