DSX™ System Service Manual 11-49
11.5 Spare Parts
Description Part Number
Optics Cube 13001010
AM module 13001020
AM Module Main board 14000290
Reference Photodiode 15000390
Drawer Connector (Module Board) 15000400
Home Sensor 15000420
Front Sensor 15000430
Filter Motor Assembly 15000450
Upper Lens Stop 22000740
Lower Lens Stop 22000750
Motor mount 22000760
Lamp access door 22000770
Module bottom cover 22000970
Belt mount 22000790
Module top cover 22000800
Nut Plate 22000830
Lens Bracket 22000840
Plate Carrier 23001350
Wear Pads 23001180
Filter Wheel 23001190
Lens Retaining Ring 23001200
Lower Gravity Block 23001220
Upper Gravity Block 23001370
Idler Shaft 23001240
Bearing Shaft Support Blocks 23001250
Bearing Shaft 23001260
Fiber Optic Assembly 24500550
Module Front Bezel 24500590
Plate Carrier Door 24500600
Upper Optics Block 24500610
Lower Optics Block 24500620
M2.5 x 12mm Flathead screws 30100080
M2 x 6mm socket head cap screws 30200040
