Manual Control Operations
5-4 DSX™ System Service Manual
5.2.4 Testing the Drawer
The Drawer test selections are listed in the right column of Figure 5-3. The self-test operation
incorporates all of the individual operations.
Figure 5-3 DSX Manual Control Dialog Box (Drawer Selections)
When you click on the Do It button, the status line will indicate that the system is performing
the operation (for example, Doing a Drawer Out Operation). At the completion of the test
operation, the message will indicate that the operation has been performed (for example,
Finished a Drawer Out operation).
