Spare Parts
DSX™ System Service Manual 13-39
13.7.6 Jigs
Part Number Description
WMFIX012 X Motor Pulley Height Setting Jig
WMFIX013 Y Motor Pulley Height Setting Jig
WMFIX014 Z Motor Pulley Height Setting Jig
WMFIX011 Y Belt Tensioning Jig
WMFIX017 X Belt Tensioning Jig
WMFIX015 Arm Positioning Jig
