15.3 Accessing Internal Components
This section describes the replacement of components for which there is a reasonable
expectation that the service engineer may be required to replace. The following conventions
are used:
Removal of components of a structural nature will not be described
It is assumed that the service engineer will remove all appropriate cables from an item
before it is removed from the system. The service engineer should remove the cable as
close as possible to the item to be removed and note the position of the cable for
reinstallation.
To access the internal components of the Ambient Drawer, remove the six M3 x 5mm screws
(shown in Figure 15-1) and remove the cover.
Upper
Enclosure
(204019601)
M3X5 Pan Head
Screw
303000305, 6X
Figure 15-1 Removing the Ambient Drawer Cover
