Spare Parts and Jigs
DSX™ System Service Manual 17-21
17.5 Spare Parts and Jigs
17.5.1 EPOD (13001410)
Part Number Description
50800140 Fan
13001410 EPOD
50500150 Inlet Switch
15001300 Live Harness
15001310 Neutral Harness
15001280 Long Earth Harness
15001260 PSU/Filter Harness
50200490 Fuse
50500160 Inlet Filter
42200300 EPOD Fan
654015003 EPOD Fan Grill
528050004 XY Printed Circuit Board
582050104 Communication Board
50100153 18,000 µf @35 v DC Capacitor
412001900 Power Supply
15001070 Cable - MOD 1 to J7 (BP)
15001050
15001050
15001050
Cable - WASH to J8 (BP)
MOD 4 to J10 (BP)
MOD 5 to J5 (BP)
15001060
15001060
15001060
Cable - MOD 2 to J9 (BP)
MOD 3 to J6 (BP)
SID to J4 (BP)
15001100 Cable - J15 X-Transition Board to J15 (BP)
15001090
15001090
Cable - J3 X-Transition Board to J14 (BP)
J2 X-Transition Board to J13 (BP)
15001110 Cable - J7 X-Transition Board to J29 (BP)
15001040 Cable - Ambient Hole to J3 (BP)
15001250 Backplane Harness
582050703 Backplane Board
