Sample ID Module
15-18 DSX™ System Service Manual
15.5.6 Spare Parts and Jigs
The following listing of parts includes all parts that are likely to be replaced by the service
engineer (screws, washers, wire and other common items are not included). In some instances,
the service engineer has the option of replacing an entire subassembly or replacing the
specific component that is defective. These components are either crucial to operation or may
be subjected to wear and tear during normal operation.
15.5.7 Ambient Drawer Assembly
Description Part Number
Timing Belt (742.5 mm) 40000050
Drive Motor 029060000
Idler Bearing (2) 322000801
Idler Support Pin 204020600
Ambient Drawer Main Circuit
Board
14000570
Optical Position Sensor 15000430
Sensor Harness 15001190
Spring (for actuating levers) 324001200
Shoulder Screws 204020200
15.5.8 Jigs
Description Part Number
Alignment Jig DMFIX010
