7.7 Spare Parts and Jigs
The following listing of parts includes all parts that are likely to be replaced by the service
engineer (screws, washers, wire and other common items are not included). In some instances,
the service engineer has the option of replacing an entire subassembly or replacing the
specific component that is defective. These components are either crucial to operation or may
be subjected to wear and tear during normal operation.
7.7.1 Z-Drive Assembly (13001440)
Description Part Number
Rotary Spring 324600400
Spring Retainer Housing 204026700
Z-Encoder 419010000
Assy., Z Home Sensor 15001180
Timing Belt (772 mm long) 400000050
Fixed Belt Block 204003300
Belt Clamp 204012400
Adjustable Belt Block 204003400
Z-Drive Block 204004600
Z-Sensor Breaker Flag 204011300
Z-Motor Pulley 320101000
Z-Motor 528300900
Z-Home Sensor 15001180
Z Sensor Plate 204005200
Bearing Plate 204004400
Idler Pulley 23001650
M4 x 6 Cone Point Set Screw 30700406
Z-Axis Transition Board 582050402
IC Mounting Plates 204026600
Insulation Pads 344001201
Pipette Assembly 13001450
Linear Bearing, 12 x 320 mm 322002000
Z Flexi Cable 15001030
