Removing External Components
11-14 DSX™ System Service Manual
11.3.4 Removal/Replacement of the Plate Carrier Door
To Remove the Plate Carrier Door:
1 Using a long punch, insert it through the side of the bezel and push the pin
through the door hinge (Figure 11-6).
One of two bezel holes
for punch insertion
Figure 11-6 Positioning the Punch Removing the Pins for the Door Hinge
