The Electronics Pod Assembly (EPOD)
DSX™ System Service Manual 17-5
17.3.3 Replacing Components in the EPOD
If it is necessary to access the interior of the EPOD, remove the lid by removing unscrewing
the six M3 x 6mm Button Head screws. An internal view of the EPOD is presented in
Figure 17-3.
Fan Capacitor PSU
Filter Communication Board XY Board
Figure 17-3 Interior of EPOD
