Dynex DSX - X-Drive Assembly (13001420); Jigs

Spare Parts and Jigs
DSX™ System Service Manual 7-59
7.7.3 X-Drive Assembly (13001420)
Description Part Number
X-Transition Board 582050902
X-Encoder 419010000
X-Axis Flexicable Platform
Bracket
204003700
X-Axis Flexicable Run Bracket 204003800
Timing Belt (1851 mm long) 40000160
X-Belt Fixed Block 204012600
X-Belt Adjustable Belt Block 204002700
X-Drive Block 204002500
IC Mounting Plate 204031400
Thin IC Mounting Plate 204011010
X-Sensor Breaker Flag 204005700
X-Axis Pulley 23001660
X-Motor 528300800
X-Main Plate 204002200
Bearing Boss 204003100
X-Opto Interrupter 15001130
X-Axis Linear Way 322001800
7.7.4 Jigs
Description Part Number
X-Motor Pulley Height Setting Jig XMFIX010
X-Belt Tensioning Jig Brecoflex Meter
Y-Motor Pulley Height Setting Jig YMFIX010
Y-Belt Tensioning Jig YMFIX012
Z-Motor Pulley Height Setting Jig ZMFIX010
Z-Belt Tensioning Jig ZMFIX012
Encoder Jig DSXFIX015
