Spare Parts
DSX™ System Service Manual 13-37
13.7 Spare Parts
13.7.1 Dispense and Aspirate Bottle Assembly
Part Number Description
354008300 Quick Connect Fitting (Dispense Bottle)
344001900 Rubber Washer (Waste Bottle)
354005900 Bulkhead Barbed Fitting (Waste Bottle)
029006600 Modified Bulkhead Barbed Fitting
(Waste Bottle)
816400600 Silicon Tubing (Waste Bottle)
62503160070 Large Elbow Fitting (Wash Bottle)
354020300 Small Elbow Fitting (Waste Bottle)
42000370 Cap (Waste Bottle)
204016500 Head Support Arm
13.7.2 X-Drive and Z-Drive Assembly (13001571)
Part Number Description
528300700 Motor
320100800 Pulley
40000050 Timing Belt
(467.5 mm, X-Drive, 192.5 mm Z-Drive
204016700 Head Support Post
204016600 Eccentric Support
204016800 Head Locking Screw
203103300 Idler Shaft (X)
15000480 Harness, Z Motor
203103300 Idler Shaft (Z)
23001990 X -Shaft
23001980 Z-Shaft
322000801 Bearings (Idler Shaft)
