Removing External Components
9-6 DSX™ System Service Manual
9.3.4 Removal/Replacement of the Plate Carrier Door
To Remove the Plate Carrier Door:
1 Insert a long punch through the side of the bezel and push the pin through the
door hinge (Figure 9-4).
One of two bezel holes
for punch insertion
Figure 9-4 Bezel Holes for Hinge Pin Removal
