Accessing Internal Components
DSX™ System Service Manual 16-7
3 Remove the M6 X 25mm screw and M6 flat washer from the upright extrusion
spring nut.
4 Disconnect dispense and aspirate tubing from the washer and pull through side
panel.
To Replace the Left Side Panel
1 Install the left-hand side panel enclosure (Part No. 204012600) and make sure
that the spring nut in the 80 X 40 upright extrusion is aligned with hole in the side
panel. If necessary, move the spring nut up (down) until it is correctly located.
2 Remove the three M6 X 12mm BHCS screws that attach the left side panel from
the top of the baseplate (two in front, one in rear) as shown in Figure 16-6.
2 Secure with one M6 X 25mm SHCS and M6 flat washer into the upright extrusion
spring nut
3 Secure with three M6 X 12 mm BHCS screws into the top of the base plate (two in
the front, one in the rear).
4 Reroute the dispense and aspirate tubing and then reconnect the washer.
Note: It may be necessary to push the side panel to the inside as far as
possible to ensure a good fit.
