Emotron VS10 - Page 200

200 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x4008:001
(P590.01)
Process input words: NetWordIN1
(NetWordINx: NetWordIN1)
0x0000 ... [0x0000] ... 0xFFFF
Mappable data word for flexible control of the inverter via network.
Bit 0 Mapping bit 0 Assignment of the function: 0x400E:001 (P505.01)
Bit 1
Mapping bit 1
Assignment of the function: 0x400E:002 (P505.02)
Bit 2
Mapping bit 2
Assignment of the function: 0x400E:003 (P505.03)
Bit 3
Mapping bit 3
Assignment of the function: 0x400E:004 (P505.04)
Bit 4
Mapping bit 4
Assignment of the function: 0x400E:005 (P505.05)
Bit 5 Mapping bit 5 Assignment of the function: 0x400E:006 (P505.06)
Bit 6
Mapping bit 6
Assignment of the function: 0x400E:007 (P505.07)
Bit 7
Mapping bit 7
Assignment of the function: 0x400E:008 (P505.08)
Bit 8
Mapping bit 8
Assignment of the function: 0x400E:009 (P505.09)
Bit 9
Mapping bit 9
Assignment of the function: 0x400E:010 (P505.10)
Bit 10 Mapping bit 10 Assignment of the function: 0x400E:011 (P505.11)
Bit 11
Mapping bit 11
Assignment of the function: 0x400E:012 (P505.12)
Bit 12
Mapping bit 12
Assignment of the function: 0x400E:013 (P505.13)
Bit 13
Mapping bit 13
Assignment of the function: 0x400E:014 (P505.14)
Bit 14
Mapping bit 14
Assignment of the function: 0x400E:015 (P505.15)
Bit 15 Mapping bit 15 Assignment of the function: 0x400E:016 (P505.16)
0x400A:001
(P591.01)
Process output words: NetWordOUT1
(NetWordOUTx: NetWordOUT1)
Read only
Mappable data word for the output of status messages of the inverter
via network.
Bit 0
Mapping bit 0
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:010 (P420.10)
Bit 1
Mapping bit 1
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:011 (P420.11)
Bit 2 Mapping bit 2 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:012 (P420.12)
Bit 3
Mapping bit 3
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:013 (P420.13)
Bit 4
Mapping bit 4
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:014 (P420.14)
Bit 5
Mapping bit 5
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:015 (P420.15)
Bit 6
Mapping bit 6
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:016 (P420.16)
Bit 7 Mapping bit 7 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:017 (P420.17)
Bit 8
Mapping bit 8
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:018 (P420.18)
Bit 9
Mapping bit 9
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:019 (P420.19)
Bit 10
Mapping bit 10
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:020 (P420.20)
Bit 11
Mapping bit 11
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:021 (P420.21)
Bit 12
Mapping bit 12
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:022 (P420.22)
