Emotron VS10 - Page 490

490 01-6203-01R3, CG Drives & Automation
Address
Name
Default setting
Category
Data type
Factor
A
M
0x1402:002
(P542.02)
RPDO3 communication parameter: Transmission
type
255
CANopen
U8
1
P
-
0x1402:005
(P542.05)
RPDO3 communication parameter: Event timer 100 ms CANopen U16 1 P -
0x1600:000
RPDO1 mapping parameter: Number of mapped
application objects in PDO
2
CANopen
U8
1
P
-
0x1600:001 RPDO1 mapping parameter: Application object 1
0x60400010
CANopen U32 1 PH -
0x1600:002
RPDO1 mapping parameter: Application object 2
0x60420010
CANopen
U32
1
PH
-
0x1600:003
RPDO1 mapping parameter: Application object 3
0x00000000
CANopen
U32
1
PH
-
0x1600:004
RPDO1 mapping parameter: Application object 4
0x00000000
CANopen
U32
1
PH
-
0x1600:005
RPDO1 mapping parameter: Application object 5
0x00000000
CANopen
U32
1
PH
-
0x1600:006 RPDO1 mapping parameter: Application object 6
0x00000000
CANopen U32 1 PH -
0x1600:007
RPDO1 mapping parameter: Application object 7
0x00000000
CANopen
U32
1
PH
-
0x1600:008
RPDO1 mapping parameter: Application object 8
0x00000000
CANopen
U32
1
PH
-
0x1601:000
RPDO2 mapping parameter: Number of mapped
application objects in PDO
0
CANopen
U8
1
P
-
0x1601:001
RPDO2 mapping parameter: Application object 1
0x00000000
CANopen
U32
1
PH
-
0x1601:002 RPDO2 mapping parameter: Application object 2 0x00000000 CANopen U32 1 PH -
0x1601:003
RPDO2 mapping parameter: Application object 3
0x00000000
CANopen
U32
1
PH
-
0x1601:004
RPDO2 mapping parameter: Application object 4
0x00000000
CANopen
U32
1
PH
-
0x1601:005
RPDO2 mapping parameter: Application object 5
0x00000000
CANopen
U32
1
PH
-
0x1601:006
RPDO2 mapping parameter: Application object 6
0x00000000
CANopen
U32
1
PH
-
0x1601:007 RPDO2 mapping parameter: Application object 7 0x00000000 CANopen U32 1 PH -
0x1601:008
RPDO2 mapping parameter: Application object 8
0x00000000
CANopen
U32
1
PH
-
0x1602:000
RPDO3 mapping parameter: Number of mapped
application objects in PDO
0
CANopen
U8
1
P
-
0x1602:001
RPDO3 mapping parameter: Application object 1
0x00000000
CANopen
U32
1
PH
-
0x1602:002
RPDO3 mapping parameter: Application object 2
0x00000000
CANopen
U32
1
PH
-
0x1602:003 RPDO3 mapping parameter: Application object 3 0x00000000 CANopen U32 1 PH -
0x1602:004
RPDO3 mapping parameter: Application object 4
0x00000000
CANopen
U32
1
PH
-
0x1602:005
RPDO3 mapping parameter: Application object 5
0x00000000
CANopen
U32
1
PH
-
0x1602:006
RPDO3 mapping parameter: Application object 6
0x00000000
CANopen
U32
1
PH
-
0x1602:007
RPDO3 mapping parameter: Application object 7
0x00000000
CANopen
U32
1
PH
-
0x1602:008 RPDO3 mapping parameter: Application object 8 0x00000000 CANopen U32 1 PH -
0x1800:000
TPDO1 communication parameter: Highest
subindex supported
(Read only)
CANopen
U8
1
-
-
0x1800:001
(P550.01)
TPDO1 communication parameter: COB-ID
0x40000180
CANopen U32 1 PH -
0x1800:002
(P550.02)
TPDO1 communication parameter: Transmission
type
255
CANopen
U8
1
P
-
0x1800:003
(P550.03)
TPDO1 communication parameter: Inhibit time
0.0 ms
CANopen
U16
10
P
-
0x1800:005
(P550.05)
TPDO1 communication parameter: Event timer
20 ms
CANopen
U16
1
P
-
0x1801:000
TPDO2 communication parameter: Highest
subindex supported
(Read only)
CANopen
U8
1
-
-
0x1801:001
(P551.01)
TPDO2 communication parameter: COB-ID
0xC0000280
CANopen
U32
1
PH
-
0x1801:002
(P551.02)
TPDO2 communication parameter: Transmission
type
255
CANopen
U8
1
P
-
0x1801:003
(P551.03)
TPDO2 communication parameter: Inhibit time
0.0 ms
CANopen
U16
10
P
-
0x1801:005
(P551.05)
TPDO2 communication parameter: Event timer
0 ms
CANopen
U16
1
P
-
0x1802:000 TPDO3 communication parameter: Highest
subindex supported
(Read only) CANopen U8 1 - -
0x1802:001
(P552.01)
TPDO3 communication parameter: COB-ID
0xC0000380
CANopen
U32
1
PH
-
