106
Changing Positions Using the Menu
(1) Display the [M/E1 KEY1 - POS/SIZE], menu PAGE1.
(2) Turn F1 or F2 to set the position of the KEY1 image.
ME1 KEY1: POSITION : SIZE :2D DVE : 1/5
POS/SIZE:X=0 Y=0 : =500 : =ON :
The base original POSITION
of a key is at the center of the output screen. You can set the
position of the key images by specifying
X and Y coordinates, with the origin of the axes
located at the center of the screen.
11-3. Changing Sizes or Aspect Ratios
Changing Sizes Using the Joystick
(1) Press POS of KEYER (2D DVE) to the left and below the joystick.
(2) Change the key size by moving the joystick clockwise and counter-clockwise.
The figures below are examples of SIZE=500 and 750 when POSITION is set to (0, 0).)
Changing Sizes Using the Menu
(1) Display the [M/E1 KEY1 - POS/SIZE], menu PAGE1.
(2) Turn F3 to set the size of the KEY1 image.
ME1 KEY1: POSITION : SIZE :2D DVE : 1/5
POS/SIZE:X=0 Y=0 : =500 : =ON :
Setting the size allows users to change the size of key images while retaining aspect ratios.
If the value is 1000, the key images will be of a full screen size.
Changing the Aspect Ratio
(1) Press the page down button to display PAGE2 of the [M/E1 KEY1 - POS/SIZE] menu.
(2) Turn F1 and F2 to change the ASPECT values for the KEY1 image.
ME1 KEY1: ASPECT :FADE LV: : 2/5
ASPECT :X=1000 Y=1000 : =0.0 : :
(The figures below are examples when POSITION is set to (0, 0).)
(500, 500)
(500, 750)
(750, 750)
SIZE(500)
SIZE(750)
