26
WEB CONTROL
9-3. VTR/VDCP
Click the VTR/VDCP tab to display and set the VTR/VDCP menu.
>> Manual Sec. 25. "VTR / VDCP Control"
Before displaying the VTR/VDCP menu, assign a channel (VTR1-4 or VDCP1-4) to an RS-422
port in the [SETUP - SYSTEM - RS-422] menu <p 11>. (VTR/VDCP controllers will not be
displayed in the menu page if channels are not assigned to ports.)
VTR channel controller VDCP channel controller
For VDCP channels, select Mira or HVS-5ECD under MODEL in the right center of the panel.
>> Manual Sec. 25-3. "Selecting the VDCP Type"
9-3-1. VTR Control
>> Manual Sec. 25-4. "Playback and Recording"
No.
Description
(1) Displays the current time code.
(2)
Displays the VTR status.
(3) REC button. Pressing the button starts recording. (See (7) REC MODE below.)
(4)
SHUTTLE/JOG/VARIABLE play buttons and playback speed controller
(5) One-frame Back, Pause, One-frame Forward
Rewind, Play, Fast Forward, Stop
(6)
Sets an IN point.
Clicking the arrow sets the current time code to the IN point.
CUE UP: Moves the play-head to the IN point time code.
(7) Sets the REC mode.
STANDARD: Starts recording by pressing REC STDBY, then REC.
DIRECT: Stars recording by just pressing REC.
