12
HVS-30OU
4-2-2. Changing Settings or Values by Using the Joystick
Users can also use the joystick and the SIZE control in the JOYSTICK block for making
position, size and color settings to specific parameters.
Controllable Parameters
See the "Changing Settings or Values by Using the Joystick" section in this main manual.
How to Use the Joystick
The general procedure for making and changing operational menu settings using the joystick
are as follows.
Open a menu page you want to set. In the example below, to change the three parameter
values (BORDER COLOR S, L and H,), use the joystick’s X, Y axes (i.e. move joystick
horizontally and vertically) and the SIZE control respectively.
ME1 WPBG: BORDER COLOR :RECALL : 2/2
BORDER :S=66.3 L=5.4 H=3.5 : >BLUE :
Resetting Values with Joystick (the SIZE control)
If you need to reset parameters controllable from the JOYSTICK block to factory default,
display parameters and then press and hold down the SIZE control. These parameters are
returned to factory default all together.
(PUSH to DEF)
SIZE
POSITION
Down
(-Y)
Up
(+Y)
Left
(-X)
Right
(+X)
Joystick operation
Joystick
SIZE button (turn)
