6-4. Clean Set Up
The switcher can output the CLEAN video via an auxiliary output. Users can also add the KEY
image to CLEAN. Follow the procedure below to assign the clean video to an AUX output. AUX3
is used in this example
Routing an M/E1 Clean Video to AUX Output
(1) Quickly press AUX1 twice in the BUS SELECT block to display the [SETUP - OUTPUT- OUT
XPT](1/4) menu.
(2) Turn F1 to select AUX3.
(3) Turn F2 to select M1CL.
OUTPUT :SELECT : XPT :INHIBIT:AUX TRS: 1/4
OUT XPT : =AUX3 : =M1CL : =OFF : =OFF :
Displaying KEY Images on M/E1 Clean
(1) Open the [SETUP - OUTPUT - CLN/PREV] menu.
(2) Turn F1 to set KEY1 to ON. Then press F1 to confirm the setting.
(3) Set KEY2 to KEY4 in the same way.
OUTPUT : KEY1 : KEY2 : KEY3 : KEY4 : 1/2
M/E1 CLN: =ON : =ON : =ON : =ON :
6-5. HDMI Output
6-5-1. Selecting the HDMI Output Video
Video output through the HDMI port can be selected from M/E program, preview, clean and
key out video, to AUX1-8 and MV1-2 as shown below.
(1) Quickly press AUX1 twice in the BUS SELECT block to display the [SETUP - OUTPUT -
OUT XPT] (1/4) menu.
(2) Press the page down button to go to PAGE 3.
(3) Turn F1 to select a video to be output from the HDMI port.
Available options are:
M/E1 PGM, M/E1 PREV, M/E1 CLEAN, M/E1 KEY
M/E2 PGM, M/E2 PREV, M/E2 CLEAN, M/E2 KEY
AUX1 to AUX8, MV1, MV2
(4) Turn F2 to select an output video format.
If in MV_HQ mode (See the next page)
1080i HDTV (1920 x 1080) *1 None
720p HDTV (1280 x 720) *1 None
SD SVGA (800 x 600) *2 HDTV (1920 x 1080) *1
*1 The HDMI output frequency for HDTV signals is the same as that used in the switcher.
*2 The HDMI output frequency can be changed to 50 Hz only when the switcher is running on 625/50
and the HDMI outputs an SVGA video signal.
Ex. 1
Switcher's System Format: 1080/59.94i
To Output the M/E1PGM video (at 1920 x 1080 resolution):
OUTPUT : XPT :FORMAT : FRQ :MV HQ : 3/4
HDMI OUT: =M1PGM: =HDTV : =--- : =OFF :
To Next Page
