68
8-2. Quick Reference for Available Transitions
Bus Type Rate
Fader
Limit
Pattern
Direction
Transition Execute Button or Tool Refer to
BLACK BLACK Available - - BLACK TRANS button 8-3
BKGD
CUT - Available - BKGD >> CUT button
8-4
MIX
Available Available - BKGD >> MIX >> AUTO button
-- Available NOR/REV Fader lever
WIPE
Available Available NOR/REV BKGD >>WIPE >> AUTO button
8-4
8-7
- Available NOR/REV Fader lever
KEY1
KEY2
CUT - Available -
KEY >> CUT button
KEY ON AIR button
KEY AUTO button
8-5
MIX
Available Available -
KEY >> MIX >> AUTO or KEY AUTO
button
KEY AUTO button
-- Available NOR/REV Fader lever
WIPE
Available Available NOR/REV
KEY >> WIPE> > AUTO or KEY AUTO)
button
8-5
8-7
- Available NOR/REV Fader lever
USER
TRANS
Available - - KEY ON AIR button 8-9
KEY3
KEY4
CUT - Available -
KEY >> CUT button
KEY ON AIR button
KEY AUTO button
8-5
MIX Available Available -
KEY >> MIX >> AUTO or KEY AUTO
button
KEY AUTO button
USER
TRANS
Available Available - KEY ON AIR button 8-9
8-3. Black Transitions
Just pressing the BLACK TRANS button can perform the BLACK transitions. Pressing the
button initiates a fade to black of whichever source is currently on air (program output). Pressing
the button again starts another fade from black to the previous video.
The BLACK transitions can be performed on the background bus.
To Set the Black Transition Rate
(1) Press the TRANSITION RATE button to display the [TRANS - BKGD/BLK] menu.
(2) Turn F4 to set the transition rate. See section 8-10-2. "Transition Rate" for details.
TRANS :BKGDTRS:EFF BGD: :BLK TRS: 1/4
BKGD/BLK: =30 : =MATT : : =30 :
