7
WEB CONTROL
4. EVENT
Click EVENT in the HOME screen to display the EVENT menu page.
>> Manual Sec. 16. "Event Memory"
Loading Events
(1) Select RECALL under CONTROL
PANEL in the center of the screen.
When using the Direct mode, set
DIRECT RECALL to ON.
(2) Select an event from the event list
on the left side. The event will be
loaded if in Direct mode.
(3) If Direct mode is OFF, the data
stored in the event will be
displayed. Select all or desired
data to be loaded.
(4) Click RECALL EXEC to load the
event.
Saving Events
(1) Select STORE under CONTROL
PANEL in the center of the screen.
(2) Select an event number in the
event list on the left side.
(3) Select data to be saved.
(4) Click STORE EXEC to store data
to the event.
(5) Clicking PREFERENCES allows
you to create a default set of event
data.
>> Manual Sec. 16-5. "Setting the
User Default Menu when Storeing
an Event."
protection
icon
protection
icon
To Next Page
