111
11-7-4. FREEZE, STROBE, NEGA, MOSAIC
Freeze, strobe, negative, and mosaic effects are also available.
(1) Go to the [M/E1 KEY1 - SUB EFF] menu PAGE 3.
ME1 KEY1:FREEZE :STROBE : NEGA :MOSAIC : 3/3
FREEZE :=OFF : =OFF : =OFF : =OFF :
(2) When applying these effects, please refer to the table below.
Parameter Description
FREEZE
Allows users to enable the freeze effect function.
Users can select either frame freeze or field freeze.
STROBE
Allows users to enable strobe effects.
Increasing the value increases the intervals of flashing light.
NEGA
Setting this function to ON makes an image negative by reversing all
luminance levels.
MOSAIC
Allows users to use a mosaic effect.
Increasing the value enlarges the size of mosaic cells.
Setting Example
ME1 KEY1:FREEZE :STROBE : NEGA :MOSAIC : 3/3
FREEZE : =FIELD: =1 : =ON : =OFF :
