6-8. AUX LINK
In the AUX-LINK function, the auxiliary outputs are grouped, and the master and slave outputs
are set to allow all slave output signals to be switched simultaneously by simply selecting the
master output signal. A group consists of one master output and up to three slave outputs.
Seven auxiliary output groups can be set. Examples of AUX LINK settings and operation are
shown below.
6-8-1. Creating AUX Output Link Groups
(1) Open the [SETUP - FUNCTION] menu. Turn F1 to select AUX LINK. Press F1 or the
page down button to display the AUX LINK menu.
SETUP :>M/E_KEY >VIRTUAL >AUX LINK
FUNCTION:
FUNCTION:ENABLE : : 1/3
AUX LINK: =OFF : :
(2) Press the page down button again to go to the [AUX LINK - AUX GRP] menu page.
FUNCTION:SELECT:MASTER: SLAVE SEL/AUX : 2/3
AUX GRP : =1 : =AUX1:1=AUX2 2=AUX3 3=AUX4
(3) Turn F1 to select a group to be set from 1-7
(4) Turn F2 to set the auxiliary output serving as the MASTER. Available outputs are shown
below.
Master Output AUX1-8, M1PG, M1PS (M2PG, M2PS)
M1-A, M1-B (M2-A, M2-B)
M1K1, M1K2, M1K3, M1K4 (M2K1, M2K2, M2K3, M2K4)
* Outputs in parentheses are available if an HVS-39EXTME is installed.
(5) Select the auxiliary outputs (up to three) serving as the SLAVE linking to the MASTER
output. Available outputs are shown below. Press F3 and then turn F3 to select an output
for Slave 1. Press F3 and then turn F3 to select an output for Slave 2. Select an output for
Slave 3 in the same way.
Slave Output
(Normal link)
Same options as Master Output.
(Note that video set as Master cannot be selected for the
Slave.
The A or B bus cannot be set for Slave when an M/E program or M/E preset bus is selected
for Master. In the same way, an M/E program or M/E preset bus cannot be set for Slave
output when the A or B bus is selected for Master.
