Page #170 background image
170
20-2. Clip Adjustment
Signal level thresholds for all color correction outputs (Clip adjustment) can be adjusted in Y/C
or RGB mode. If Clip adjustment is disabled (ENABLE to OFF), default values are applied to
output signals.
<To Set Clip in Y/C Mode:>
(1) Open [SETUP - INPUT - CC] menu PAGE 5.
(2) Turn F4 to set ENABLE to Y/C.
(3) Turn F1 to F3 to set each parameter limit respectively.
INPUT : Y/C CLIP :ENABLE : 5/6
CC CLIP :YW=109%:YB=-7% :C=111% : =ON :
Parameter Description Default Setting
YW
Sets the WHITE limit in Y signal.
(See below in this page.)
109% 50% to 109%
YB
Sets the BLACK limit in Y signal.
(See the next page.)
-7% -7% to 50%
C Sets the WHITE limit in C signal. 111% 50% to 111%
<To Set Clip in RGB Mode:>
(1) Open the [SETUP - INPUT - CC] menu PAGE 5.
(2) Turn F4 to set ENABLE to RGB.
(3) Turn F1 to F3 to set each R, G and B limit for WHITE in PAGE 5 and for BLACK in PAGE 6.
INPUT : RGB WHITE CLIP :ENABLE : 5/6
CC CLIP :R=300% :G=300% :B=300% : =RGB :
INPUT : RGB BLACK CLIP :ENABLE : 6/6
CC CLIP :R=-200%:G=-200%:B=-200%: =RGB :
Page Parameter Description Default Setting
Page 1
WHITE
R / G / B
Sets the WHITE limit using R, G and B.
(See below.)
300% 50% to 300%
Page 2
BLACK
R / G / B
Sets the WHITE limit using R, G and B.
(See the next page.)
-200% -200% to 50 %
Y/C Mode and RGB Mode
Y/C mode
Y White Clip
Adjustable Range 50 to 109%
Default setting: 109%
100% color bars when 100% white
109%
100%
50%
50%
0%
Y White Clip level range
