22
WEB CONTROL
7-2-2. Backing Up/Loading Stills and Clips (HVS-39MB)
If an HVS-39MB is installed in the switcher, all still and clip data including INPUT STILL data
can be backed up.
>> Manual Sec. 12-4. "Backing-up Still and Clip Data (HVS-39MB)"
To Back-up Data
Open the [STILL - BACKUP] menu page and set HVS-39MB BACKUP to ON.
The HVS-39MB allows you to automatically save all still and clip backup data. Automatic
backup is performed every time the user stores an image or clip to a buffer, STILL1-4,
INPUT_STILL1-16 or CLIP1-4.
Automatic backup is performed:
-When still images are sent to STILL1-4 or INPUT_STILL1-16 from the OU via a USB flash
drive.
-When still images or clips are sent to STILL1-4, INPUT_STILL1-16 or CLIP1-4 via FTP.
-When still images are captured from input video and saved to STILL1-4.
Each item of backup data can be automatically loaded at startup as well as manually loaded
as needed.
To Load Data (manually)
Loading data to STILL1-4 or CLIP1-4
Drag and drop the BACK UP DATA icon to a still memory box in the [STILL - BACKUP] menu.
A dialog box will appear. Select STILL or CLIP.
Loading data to INPUT STILL1-16:
Press LOAD under STIL CTRL in the [SETUP - INPUT - SIGNAL] menu. If an INPUT STILL
buffer already contains still data, load the backup data after clearing the previous data.
Auto backup:
Set to ON:
Manual Loading:
Drag and drop
