About HVS-390 series system configuration
The HVS-390HS is the main unit for HVS-390 series systems. The following standard
control panels are available. (HVS-30OU and HVS-30RU can also be used.) These control
panels can exist together in the same system.
HVS-391OU: A full-featured 1 M/E control panel.
HVS-392OU: A full-featured 2 M/E control panel.
HVS-392ROU: A compact 2 M/E control panel (designed for rack mount use)
Other Options
ITEM QTY REMARKS
HVS-30RU 1-2 Remote Control Unit
HVS-AUX8 1-5 AUX bus Control Box (Hanabi Series Option)
HVS-AUX16 1-5 AUX bus Control Box (Hanabi Series Option)
HVS-AUX32 1-5 AUX bus Control Box (Hanabi Series Option)
HVS-AUX8RK,
HVS-AUXRK
1
Remote Kit for Aux bus Control Box
(Hanabi Series Option)
HVS-TALR20/32 (*1) 1-3
Tally Control Unit (Relay type)
(Hanabi Series Option)
HVS-TALOC20/32 (*1) 1-3
Tally Control Unit (Open Collector type)
(Hanabi Series Option)
Control Cable 1
BNC cable for ARCNET connection
(10 m) , (BNC 5C2V 75Ω)
(*1) Multiple HVS-TALOC / HVS-TALR configurations possible; up to 3 units max.
Optional devices or software are basically provided with the installation manuals (except
factory- installed ones) or specific operation manuals.
About This Manual
This manual is intended to help the user easily operate Hanabi series switchers and make full
use of their functions during operation. Before configuring or operating your system, read this
operation manual thoroughly to ensure you understand the product. Afterwards, it is important to
keep this manual in a safe place and available for future reference.
Font Conventions
The following conventions are used throughout this manual:
Boxed text (for example MATT, F1, TRANS, and AUX1) is used to indicate the control panel
buttons
Bold text (such as SIGNAL, TYPE and COLOR) is used to indicate the
.
setting parameters
Shaded text (such as MATT, ON, OFF, 50.0, 30, and PGM) is used to indicate the
in menus.
setting
values
Text enclosed by square brackets (such as [SETUP - SYSTEM]) indicate
in menus.
menu names
.
