FOR-A HVS-390HS User Manual

16
HVS-30OU
6-2. Available Transitions
Bus Type
Transition
Rate Setting
Fader Limit
Setting
Wipe Direction
setting
Transition Execute
Button or Tool
BLACK BLACK Available － － BLACK TRANS button
BKGD
CUT － Available － BKGD >> CUT button
MIX
Available Available － BKGD >> MIX >> AUTO button
- Available NOR/REV Fader lever
WIPE
Available Available NOR/REV BKGD >> WIPE >> AUTO button
- Available NOR/REV Fader lever
KEY1
CUT － Available －
KEY >> CUT button
KEYER ON AIR button
KEYER AUTO button
MIX
Available Available －
KEY >> MIX >> AUTO button
KEYER AUTO button
－ Available NOR/REV Fader lever
WIPE
Available Available NOR/REV KEY >> WIPE >> AUTO button
－ Available NOR/REV Fader lever
USER
TRANS
Available － － KEY ON AIR button
KEY2
CUT － Available －
PinP1 ON AIR button
PinP1 AUTO button
MIX Available Available － PinP1 AUTO button
USER
TRANS
Available － － PinP1 ON AIR button
KEY3
CUT － Available －
PinP2 ON AIR button
PinP2 AUTO button
MIX Available Available － PinP2 AUTO button
USER
TRANS
Available － － PinP2 ON AIR button
KEY4
CUT － Available －
DSK ON AIR button
DSK AUTO button
MIX Available Available － DSK AUTO button
USER
TRANS
Available － － DSK ON AIR button
6-3. Black Transitions
Just pressing the BLACK TRANS button can perform the BLACK transitions. Pressing the
button initiates a fade to black of whichever source is currently on air (program output). Pressing
the button again starts another fade from black to the previous video.
The BLACK transitions can be performed on the background bus.
 To Set the Black Transition Rate
(1) Press the TRANSITION RATE button to display the [TRANS - BKGD/BLK] menu.
(2) Turn F4 to set the transition rate.
TRANS :BKGDTRS:EFF BGD: :BLK TRS: 1/4
BKGD/BLK: =30 : =MATT : : =30 :
