216
29. Editor Control (Option)
The switcher can be controlled from an editor. See section 29-1."Editor Control Settings" for
controlling the editor and section 29-2 "Connection Settings with Editor (EDITOR port setting)" for
editor connection.
The HVS-39ED software option is required for editor control.
29-1. Editor Control Settings
(1) Open the [SETUP - EXT I/F - EDITOR] menu.
SETUP :>EDITOR >TSL TLY >VTR >ROUTER
EXT I/F :>AUD XPT
(2) Select a protocol at TYPE between DVS(SONY DVS/BVS series compatible) and GVG-K/Z.
(3) Set ENABLE to ON to enable the editor control. (The Editor Control On/Off function can be
assigned to a USER button. See section
0. "USER Button.")
FUNCTION: TYPE :ENABLE :SELECT : WIPE : 1/2
EDITOR :=DVS : =ON : =ME : =NORML:
(4) If DVS is used, the bus to be controlled from the editor must be specified. Refer to the table
below to set the bus under SELECT. If PREV, PREV ON or ALL is set, AUX1 will be the edit
preview bus and with crosspoint number is 35. Set your editor accordingly.
Setting Description
ME Controls the M/E bus when ENABLE is ON.
PREV Controls the preview bus when ENABLE is ON.
ALL Controls both M/E bus and preview bus when ENABLE is ON.
ME ON
Always controls the M/E bus regardless of ENABLE setting.
Controls both M/E bus and preview bus when ENABLE is ON.
PREV ON
Always controls the preview bus regardless of ENABLE setting.
Controls both M/E bus and preview bus when ENABLE is ON.
(5) If G-K/Z (GVG protocol) is used, select the pattern control mode between two below at WIPE.
Setting Description
NORMAL
Same wipe pattern numbers (0-99) as in the switcher are used in the editor.
(default setting)
LIST
Ten wipe patterns saved to Direct Pattern memory are used in the editor as
Direct Pattern Nos. 90-99. (GVG-Protocol only)
(6) Press the page down button to go to PAGE2.
FUNCTION:XPT CTL:WIP CTL:KEY CTL: : 2/2
EDITOR : =INPUT: =ON : =ON : :
