215
AUD XPT Setting
Setting Description
NONE
Audio selection is not changed, maintaining the last selection, whenever
any video signal is selected.
1-64
When the specified video signal (set under SIGNAL parameter) is
selected on an M/E, Audio Mixer changes audio to the specified bus
FLWME This setting is available only for M/E1 (re-entry) on the M/E2.
Audio Mixer changes audio to the same bus as assigned to the input
signal selected on the M/E1 PGM.
(See the setting example in the next page.)
Setting Example when using Re-entry
In the following menu settings, if the M/E1 bus signal is changed to IN04 on the switcher, the
audio playback is changed to No. 1 on the Audio Mixer.
In addition, when the M/E2 bus is set to FLWME for the M/E1 signal as shown below, the
audio playback is set to No. 1 on the Audio Mixer if the M/E1 re-entry signal is selected on the
M/E2 bus and the M/E1 bus signal is changed to IN04. (M/E2 is available only when an
HVS-39EXTME option is installed.)
EXT I/F :ENABLE : BUS :SIGNAL :AUD XPT: 1/1
AUD MXR : =ON : =M/E1 : =IN04: =1 :
EXT I/F :ENABLE : BUS :SIGNAL :AUD XPT: 1/1
AUD MXR : =ON : =M/E2 : =M/E1: =FLWME:
Default Video and Audio Assignments
Video Audio bus
BLACK NONE
IN01 to IN24 1 to 24
STILL1 to 4 NONE
STILLKEY NONE
MATTE1 NONE
MATTE2 NONE
COLORBAR NONE
M/E1 NONE
To Next Page
