13
HVS-30OU
5. Bus Operation
The video signals input to the switcher are assigned to the bus buttons on the control panel for
usage. The assigned signals are shared by the M/E1, M/E2, and KEY/AUX bus sections. Video
inputs, Stills and Mattes can be assigned to the bus buttons which work in the same way as those
on the HVS-391OU/392OU/392ROU.
5-1. Selecting Video Sources
5-1-1. Selecting M/E1 or M/E2
The HVS-30OU units have a single M/E bus, however the HVS-390HS units have two. This
requires that the bus to be controlled, M/E1 or M/E2, must be chosen before starting the
switcher operation as shown below.
NOTE
The M/E selection also affects the transition control.
(1) Press the MENU control button.
(2)Pess the SETUP button to display the SETUP menu’s top page.
(3) Turn F1 to select INPUT. Then press F1 or the PAGE DOWN button to display the
[SETUP- INPUT] menu.
(4) Turn F1 to select ASSIGN. Press F1 or the PAGE DOWN button to display the [SETUP-
INPUT- ASSIGN] menu.
SETUP :>SIGNAL >PROC AMP>RENAME >ASSIGN
INPUT :>CC >COLORBAR
(5) Press PAGE DOWN to go to PAGE4. The CONTROL item, which determines the
HVS-30OU controls M/E1 or M/E2 of the HVS-390HS, appears.
(6) Turn F4 to select a bus to be controlled.
INPUT :SELECT : SHIFT : LINK :CONTROL: 4/4
ASSGN : =OU : =TOGLE: =OFF : =M/E1 :
