80
8-10. Advanced Settings for Transitions
8-10-1. Fader Limit
The fader limit setting determines how far your transition can proceed. When performing
transitions (mix or other) there may be times when you want the transition to the next signal to
only complete to a certain degree instead of fully switching from one picture to another. In
such case, you will need to limit the fader range. The procedure to do this is as follows.
(1) Press the FADER LIMIT button in the TRANSITION block to display the [TRANS - LIMIT]
menu. Set the fader limit value at L (Limit). The default setting is 100.0. With this setting,
the transition is complete with pictures switching fully. Set E (Enable) to ON to enable the
fader limit function.
M/E TRS : BKGD : : 1/3
LIMIT :L=100.0:E=ON : :
(2) Press the page down button to go to the following pages and set the fader limit for keys in
the same way.
The FADER LIMIT buttons turn on when the fader limit function is enabled. Pressing the
FADER LIMIT buttons on the fader levers toggle the fader limit feature of the background to
ON or OFF.
(3) Press AUTO or move the fader lever to perform transitions.
Adjusting the Fader Offset:
The fader OFFSET for the lever can also be adjusted in the [SETUP - PANEL - TRS CTRL]
menu. Turn F3 and F4 to adjust the fader offset.
PANEL :BUSTYPE:ON AIR : FADER OFFSET : 1/1
M/E CTRL: =P/P : =RED :U=1.00 L=1.00 :
Item Setting Description
FADER
OFFSET
U Sets the upper edge offset.
Sets the bottom edge offset.
To Next Page
