6-3. Preview Set Up
The switcher does not have a dedicated PREVIEW output. The preview bus output can be
assigned to, however, an SDI OUTPUT or AUX output. Users can also add the key images to
PREVIEW. This can be done as explained below:
6-3-1. Preview Bus Monitoring
Follow the procedure below to assign the preview video to an AUX output. AUX1 is used in
the example below.
(1) Quickly press AUX1 twice in the BUS SELECT block to display the [SETUP - OUTPUT -
OUT XPT] (1/4) menu.
(2) Turn F1 to select AUX1.
(3) Turn F2 to select M1PV.
OUTPUT :SELECT : XPT :INHIBIT:AUX TRS: 1/4
OUT XPT : =AUX1 : =M1PV : =OFF : =OFF :
6-3-2. Setting Up Preview Images
(1) Open PAGE 2 in the [SETUP - OUTPUT - CLN/PREV] menu.
(2) Turn F1 to F4 to set whether the key images are to be displayed on the preview image,
then press the push-button to confirm the setting for each.
OUTPUT : KEY1 : KEY2 : KEY3 : KEY4 : 2/2
M/E1 PRV: =ON : =ON : =OFF : =OFF :
Item Setting NEXT TRANSITION
KEY
On-Air/Off-Air
KEY image on
PREVIEW
PREVIEW
OUT -
KEY1-4
ON KEY button ON On-Air Not displayed
ON KEY button OFF On-Air Displayed
ON KEY button ON Off-Air Displayed
ON KEY button OFF Off-Air Not displayed
OFF --- --- Not displayed
* Whether the KEY images are displayed on the preview depends on both the PREVIEW OUT settings
and KEY button status in the NEXT TRANSITION section.
* The M/E2 PREV setup is possible, if an HVS-39EXTME is installed.
