199
25-4. Playback and Recording
Four pages of the [VTR/VDCP] menu contain the following control commands.
Item F1 - F4 control Description
1/4 SELECT F1 Turn Selects a VTR or VDCP channel for control.
DRCT REC
(DIRECT REC)
F3 Turn Sets DIRECT REC mode to ON or OFF.
2/4 STOP F1 Press Stops the device operation.
REC
F2+
F3
Press
Starts recording by pressing F3 while holding down F2
when DIRCT REC is Off.
F2 Press
Starts recording by pressing F2 when DIRECT REC is
ON.
PLAY/PAUSE F3 Press
Starts playback.
Pauses playback while playing back video.
REW/FF
F4 Press
Rewinds or fast-forwards tapes or other video storage
media.
F4 Turn Switches between REW and FF.
3/4
CUE UP F1 Press
Cues up to a location specified by time code value.
Set the time code value in the following way.
TC Input F3
Press &
turn
1) Press F3 to enable TC Input mode.
2) Enter a value by turning F3 or using the keypad.
The time code for CUE UP should be set in hh/mm/ss/ff
format.
3) Press F3 to set the time code.
Turn
Increases or decreases the time code value in a
per-frame basis by turning F3 without pressing F3
beforehand, if time code is already set.
4/4
SHTL
F1 Press Changes the device to shuttle mode.
F2 Turn Selects the shuttle mode speed.
VAR
F2 Press Changes the device to variable mode.
F2 Turn Selects the variable mode speed.
STEP-R F3 Press Reverses the current time code by one frame.
STEP-F F4 Press Advances the current time code by one frame.
* VTR control does not support CTL timecode. TC display, CUE UP, STEP-R, and STEP-F do
not work properly if the connected device uses CTL timecode.
25-5. Assigning Functions to User Buttons
The following VTR/VDCP functions can be assigned to user buttons.
VTR/VDCP menu shortcut
Channel Enable / Disable
VTR1 SELECT VDCP1 SELECT
VTR2 SELECT VDCP2 SELECT
VTR3 SELECT VDCP3 SELECT
VTR4 SELECT VDCP4 SELECT
VTR commands
REW, PLAY/PAUSE, FWD, STOP, REC, STEP FWD and STEP REW
VDCP commands
REW, PLAY/PAUSE, FWD, STOP, REC, STEP FWD, STEP REW
MARK IN and MARK OUT
See section 22. "USER Button" for details on assigning functions to user buttons.
