20-1-2. Adjusting Colors
Now the selected video signal can be processed using Color Correction. Check and adjust
the signal using a waveform monitor and vectorscope. Also use an SDI monitor to compare
between pre- and post-processed images.
(1) In the [SETUP - INPUT - CC] menu, turn F4 to set ENABLE to ON to enable color
correction.
INPUT :SELECT : TYPE :SIGNAL :ENABLE : 1/6
CC TOP : =M1Ch1: =INPUT: =IN01 : =ON : M1-1
(2) Go to [SETUP - INPUT - CC] menu PAGE 2.
(3) Turn F1 to select the color correction mode from BAL (balanced), DIF (DIFFERENTIAL)
and SEPIA (Sepia) under MODE.
INPUT : WHITE LEVEL : MODE : 2/6
CC WHITE:R=100% :G=100% :B=100% : =BAL : M1-1
<If Balance or Differential is selected:>
Set signal levels for WHITE, BLACK and GAMMA in PAGE 2 to 4. Set levels for R,G and B
components respectively using F1 to F3 for each. In the CC GAMMA menu, turning F4
allows you to select the gamma curve type.
INPUT : WHITE LEVEL : MODE : 2/6
CC WHITE:R=100% :G=100% :B=100% : =BAL : M1-1
INPUT : BLACK LEVEL : : 3/6
CC BLACK:R=100% :G=100% :B=100% : : M1-1
INPUT : GAMMA LEVEL : CURVE : 4/6
CC GAMMA:R=100% :G=100% :B=100% : =CENTR: M1-1
Page Parameter Description Default Setting range
Page 2
WHITE
R / G / B
Adjusts R, G and B.
(See p. 168.)
100% 0% to 200%
Page 3
BLACK
R / G / B
Adjusts R, G and B.
(See p.169.)
100% 0% to 200%
Page 4
GAMMA
CURVE
Selects gamma curve.
(See p.169.)
CENTER CENTER, BLACK, WHITE
<If Sepia is selected:>
Use F1 and F3 to adjust SAT and HUE in PAGE 2.
INPUT : SEPIA LEVEL : MODE : 2/6
CC SEPIA:S=100% : :H=100 : =SEPIA: M1-1
Page 2
SEPIA
SAT Adjusts R, G and B. 25 0 to 100
HUE Adjusts hue. -160 -179 to 180
To Next Page
